UNI-T UTD2052CEX+ oscilloscope
Details
The UNI-T UTD2052CEX+ is a 2 channel oscilloscope with an outstanding price-quality ratio. The scope has a high bandwidth of 50MHz and a large sample rate of 1GSa/s. What makes this product so special is that the memory depth of 64kpts is quite high in comparison with its competitors (for instance the Owon SDS1102) and its predecessor UTD2052CEX.
Furthermore, an USB-interface is available for storage of signals and measurements.
Specifications
| Bandwidth | 50MHz |
| Channels | 2 |
| Sample rate | 1 GSa/s |
| Memory depth | 64 kpts |
| Waveform capture rate | >5000 wfms/s |
| Trigger types | Edge, pulse, alternate,slope, video |
| Vertical scale | 1 mV/div - 20 V/div |
| Horizontal scale | 2 ns/div - 50 s/div |
| Display | 7" 800x480 TFT LCD |
| Weight | 2.5 kg |
| Dimensions | 306 x 138 x 124 mm |
Accessories
The UNI-T UTD2102CEX+ gets delivered including:
- Power cord
- USB interface cable (UT-D14)
- 2x passive probe (1 x , 10 x switchable,50MHz) (UT-P03)
Downloads
| UTD2000 series manual |  (2.03 MB) | Download |
| UTD2000CEX+ series datasheet | (292.96 KB) | Download |
