The UNI-T UT210E is a handheld multimeter with an integrated fork. This meter can measure, AC and DC current up to 200A safely. Furthermore, this multimeter can also measure DC/AC voltages up to 1000V, resistance and capacity. The 6000 counts display shows just enough for all basic applications.
Measurements can be performed by sticking a wire between the two ends of the fork, enabling you to measure non-stripped wires. With the NCV-meter on the point of the fork, it is possible to measure if there is a voltage on the wire.
Specifications
| Measurement range and accuracy |
| Max. DC voltage | 1000 V (± 1.2% + 3) |
| Max. AC voltage | 1000 V (± 0.8% + 3) |
| Max. DC current | 200 A (± 2.5% + 5) |
| Max. AC current | 200 A (± 2.5% + 5) |
| Resistance | 0.1 Ω ~ 60 MΩ (± 1% + 2) |
| Capacitance | 1 pf ~ 60 mF (± 4% + 20) |
|
| Measurement category |
CAT II 1000 V and CAT III 600 V |
| Display resolution |
6000 counts |
| Other functions |
Auto range, True RMS, diode test, data hold, auto power off, full icon display and low battery indication |
| Power |
2 x AA 1.5 V batteries |
| LCD size |
36.5 mm x 24 mm |
| Weight |
248 g |
| Dimensions |
210 mm x 53 mm x 35 mm |
Accessories
The UNI-T UT210E comes with:
- Test leads
- 2 x AA batteries
- Carrying bag
Downloads
(9.78 MB)
