This near-field probe set consists of 3 magnetic field probes (20, 10, and 5 mm resolution) and 1 electric field probe (5 mm resolution), which makes it suitable for pre-compliance testing of PCBs. Measuring magnetic fields in and around PCBs is one of the most important measures against interference issues. These probes are connected to the 50 Ω input of a spectrum analyzer or oscilloscope and are able to measure magnetic fields and disturbance currents in the frequency range of 300 KHz - 3 GHz.
This set includes a soft carrying bag, a N-SMA cable (70cm), and an N-BNC adapter.
Specifications
Resolution magnetic field probes | 20, 10 and 5 mm |
Resolution electric field probe | 5 mm |
Frequency range | 300 KHz - 3 GHz |
