692.1

Regular Price: €769.00

Now: €692.10 Excl. VAT

Please ask for lead time

Be the first to review this product

Details

The SPS5051X from Siglent is a single channel programmable switching DC power supply with a maximum voltage of 50 V, a maximum current of 10 A and a maximum power of 180 W. This power supply can be connected in series (2 units) or in parallel (3 units), check the datasheet for more information about connection possibilities.
The SPS5051X has a bright 2.4 inch OLED screen and a user-friendly interface. It also provides high resolution voltage and current settings, adjustable slew rates, on-device and through USB/LAN list sequence programming, analog control, and over-voltage, current, power and temperature protection. These features make the SPS5051X an ideal choice for demanding users.

Models

The models differ in the amount of channels, maximum voltage, current and output power.

ModelSPS5041X SPS5042X SPS5043X SPS5044X SPS5045X
Channels 1 1 1 2 3
Voltage 40 V 40 V 40 V 40 V 40 V
Current 30 A 60 A 90 A 30 A 30 A
Output power 360 W 720 W 1080 W 360*2 W 360*3 W
Price 755.1 Regular Price: €839.00 Now: €755.10 Excl. VAT 926.1 Regular Price: €1,029.00 Now: €926.10 Excl. VAT 1205.1 Regular Price: €1,339.00 Now: €1,205.10 Excl. VAT 1421.1 Regular Price: €1,579.00 Now: €1,421.10 Excl. VAT 1691.1 Regular Price: €1,879.00 Now: €1,691.10 Excl. VAT
Model SPS5051XSPS5081X SPS5082X SPS5083X SPS5084X SPS5085X
Channels 1 1 1 1 2 3
Voltage 50 V 80 V 80 V 80 V 80 V 80 V
Current 10 A 15 A 30 A 45 A 15 A 15 A
Output power 180 W360 W 720 W 1080 W 360*2 W 360*3 W
Price 692.1 Regular Price: €769.00 Now: €692.10 Excl. VAT 899.1 Regular Price: €999.00 Now: €899.10 Excl. VAT 1115.1 Regular Price: €1,239.00 Now: €1,115.10 Excl. VAT 1457.1 Regular Price: €1,619.00 Now: €1,457.10 Excl. VAT 1565.1 Regular Price: €1,739.00 Now: €1,565.10 Excl. VAT 1880.1 Regular Price: €2,089.00 Now: €1,880.10 Excl. VAT
Model SPS5161X SPS5162X SPS5163X SPS5164X SPS5165X
Channels 1 1 1 2 3
Voltage 160 V 160 V 160 V 160 V 160 V
Current 7.5 A 15 A 22.5 A 7.5 A 30 A
Output power 360 W 720 W 1080 W 360*2 W 360*3 W
Price 899.1 Regular Price: €999.00 Now: €899.10 Excl. VAT 1115.1 Regular Price: €1,239.00 Now: €1,115.10 Excl. VAT 1457.1 Regular Price: €1,619.00 Now: €1,457.10 Excl. VAT 1565.1 Regular Price: €1,739.00 Now: €1,565.10 Excl. VAT 1880.1 Regular Price: €2,089.00 Now: €1,880.10 Excl. VAT

Specifications

Maximum power 180 W
Maximum voltage 50 V
Maximum current 10 A
Resolution 1 mV / 1 mA
Channels 1
Ripple 4 mV RMS / 10 mA RMS
Protection functions OVP, OCP, OTP, Low AC Input Protection, LPP
Connectivity USB, LAN
Connector type Screw
Dimensions 71 x 124 x 418 mm
Weight 3.3 kg

Accessories

The Siglent SPS5051X comes delivered with:

  • USB cable
  • Power cord
  • Output test cord (10A)
  • Output guard

Pros and cons

  • Suitable for industrial applications
  • Versatile use
  • Upper price segment
