The GW Instek MSO-2204EA is a 4-channel oscilloscope with 200MHz bandwidth.
The MSO-2204EA also features a built-in 16 Channel Logic Analyzer and Dual Channel 25MHz Arbitrary Waveform Generator.
The scope is equipped with an 8" display and has a high sample rate of 1GS/s per channel.
Specifications
| Bandwidth | 200 MHz |
| Channels | 4 |
| Memory depth | 10 Mpts (per channel) |
| Sample rate | 1 GS/s (per channel) |
| Waveform capture rate | 120,000 wfm/s |
| Vertical resolution | 8 bits |
| Vertical scale | 1 mV/div - 10 V/div |
| Horizontal scale | 1 ns/div - 100 s/div |
| Interfaces | USB Host, USB Device, LAN, Go / NoGo |
| Decoding | IIC, SPI, UART(RS232/422/485), CAN, LIN |
| Display | 8" TFT LCD (800x480) |
| Dimensions | 384 x 208 x 127.3 mm |
| Weight | 2.8 kg |
