Fluke T150 voltage tester
Details
The Fluke T150 is a two-pole voltage and continuity tester which can measure up to 690V. This tester features large, easy-to-use buttons, an electric torch, and a bright backlit LED indicator and display. This makes it suited for nearly any work situation. The T150 is also equipped with tactical and audible feedback to indicate the presence of voltage. Especially the tactical feedback is something that stands out in comparison to other testers. This model is also capable of resistance measurement up to 1999Ω.
The T150 can measure continuity, voltage, resistance, and phase rotation. Even when the device its batteries are empty, it will still indicate whether there is a voltage present to prevent dangerous situations. Next to this, the voltage tester features some advanced functionality such as data hold and RCD tests.
Compare models
The main difference between the models is their capability to make resistance measurements.| Model | T130 | T150 |
|---|---|---|
| Resistance measurement | - | 1999 Ω |
| Price |
Specifications
| Voltage | 6 V - 690 V |
| Continuity | 0 - 400 kΩ |
| Supported frequency | 0/40 Hz - 400 Hz |
| Phase rotation | 100 V - 690 V |
| Response time | < 0,5 s |
| Safety Category | CAT III 690 V & CAT IV 600 V |
| Power source | 2 x AAA |
| Dimensions | 23 x 6.5 x 3,8 cm |
| Weight | 180 g |
Accessories
The T150 includes:
- Batteries
- Test lead caps
Downloads
| Fluke T150 datasheet |  (178.65 KB) | Download |
