Zeroplus LAP-C 16064 logic analyser

With the Zeroplus LAP-C 16064 USB logic analyser, you can quickly and clearly visualise up to 16 digital signals. You can also view raw data; however, the support of many known protocols makes analysing bus signals effortless.

Thanks to the USB connection, no external power adapter is required, and fast data transfer is possible. The patented data compression ensures that up to 255x more data can be recorded, so less memory is needed.

The ZeroPlus DSO Module adds dual-channel oscilloscope functionality to your LAP-C 16000/32000 series, allowing you to capture and analyse analog waveforms alongside digital logic signals in a single measurement session. Combine up to 2 DSO channels with 7 logic analyser channels for comprehensive mixed-signal debugging.

Software

A very extensive software package can be downloaded here. The Zeroplus software allows you to decode the protocols of the signals you are viewing. For example, you can read CAN, I2C or UART messages directly in the Zeroplus software. As many as 120 protocols are directly supported. Do you want more information about decoding SPI and/or CAN signals? Then see the videos below.

In the table at the bottom of the page, an overview of a number of supported protocols can be found.

Overview protocols

Below is an overview of the protocols that come standard with the LAP-C logic analyser. You can download the complete software set here.

Accessories

The LAP-C 16064 logic analyser is supplied with:

• 1x USB 2.0 cable
• 20x clip-on hooks
• 1x Driver CD
• 1x 1-pin probe
• 1x 2-pin probe
• 2x 8-pin probe
• 1x Carrying bag

Downloads

LAP-C manual

(4.69 MB)

Download
