Weller WXA 2010 hot air soldering station
Details
The Weller WXA 2010 hot air soldering station is suitable for resoldering circuit boards. Thanks to the two channels present on the WXA 2010 it is possible to operate two soldering tools simultaneously. The WXA 2010 is meant to be operated with external compressed air, has a power of 255W, a temperature range of 100 °C - 550 °C and comes with a hot air tool. Moreover, the WXA 2010 is compatible with the entire WX-series hot air tools, soldering irons (such as the Weller WXHAP 200 hot air soldering iron) and desoldering tweezers; feel free to contact us for more information. Other features of the WXA 2010 are its data logging capabilities, RS232 programmability and standby-mode that reduces energy consumption while the station is not in use.
Specifications
| Power | 255 W |
| Temperature range | 100 °C - 550 °C |
| Temperature accuracy | 9 °C |
| Air flow control | 1-20 standard L/min |
| Interface | 1x USB, 2x RS232 |
| ESD safe | Yes |
| Automatic standby | Yes |
| Dimensions | 174 x 154 x 135 mm |
| Weight | 4 kg |
Accessories
The WXA 2010 comes by default with:
- WDH 30 hot air tool holder
- WXHAP 200 hot air tool
- R04 hot air nozzle round (1.2 mm)
- R06 hot air nozzle (3.0 mm)
- Power cable
Pros and cons
- Has two channels
- Compatible with all the WX series hot air tools, soldering irons and desoldering tweezers
- Possible to log data with a usb-interface
- Possible to combine with the Weller Zero Smog fume extractor
- High price
Downloads
| Weller WX1 interface manual |  (2.79 MB) | Download |
| Weller WXA Datasheet | (1.42 MB) | Download |
