Velleman LABPS3003SM power supply 0-30V 0-3A with LCD
Details
The Velleman LABPS3003SM power supply is an accurate, DC-controlled power supply with an adjustable output and safety connector (IEC 1010). Moreover, the output of the power supply can be used for a constant voltage (CV) and a constant current (CC). Furthermore, the LABPS3003SM can deliver an output power of 90 W. The power supply is equipped with a 4-digit LED display to show the current and voltage. Lastly, this power supply has a current limiting function.
An identical power supply with a screw connector instead of a safety connector can be found on this page
Specifications
| Total power | 90 W |
| Outputs | 1 |
| Output switch | Yes |
| Voltage range | 0 - 30 V |
| Current range | 0 - 3 A |
| Ripple | ≤ 200 mVp-p |
| Protection | OCP |
| Dimensions | 85 x 160 x 205 mm |
| Weight | 1.334 kg |
Accessories
The power supply comes with the following accessories:
- Power cord
Pros and cons
- Has a safety connector
Downloads
| Velleman LABPS3003SM power supply manual |  (515.66 KB) | Download |
