UNI-T UDP6722 Power Supply

545 €545.00 Excl. VAT
Loading stock info
  •
Product number: ELE006469

Be the first to review this product

Lowest price guaranteed

Details

The UNI-T UDP6722 is a single channel 80V, 8A, 400W power supply, featuring a full color TFT LCD display, a high full scale resolution with a maximum of 600 memory presets.

Models

The models differ in the maximum voltage, current and output power.

ModelUDP6720 UDP6721 UDP6722 UDP6730 UDP6731
Channels 1 1 1 1 1
Voltage 0～60 V 0～60 V 0 ~ 80 V 0～40 V 0～80 V
Current 5 A 8 A 20 A 30 A 15 A
Output power 100 W 180 W 400 W 360 W 360 W
Price 190 €190.00 Excl. VAT 265 €265.00 Excl. VAT 545 €545.00 Excl. VAT 335 €335.00 Excl. VAT 360 €360.00 Excl. VAT

Specifications

Maximum power 400 W
Maximum voltage 80 V
Maximum current 20 A
Resolution 10 mV / 10 mA
Channels 1
Ripple <5.0 mV RMS / <8.0 mA RMS
Protection functions OVP, OCP, OTP
Connectivity RS232, RS485, LAN & USB.
Connector type RS232, RS485, LAN & USB.
Dimensions 87 x 174 x 255 mm
Weight 2.5 kg

Accessories

The UNI-T UDP6722 comes delivered with:

  • Power cord

Pros and cons

  • Highly accurate
  • Supports SCPI protocol
  • Multiple connection options
  • Low maximum power output
  • Single channel
