JBC MVE-A pneumatic desoldering pump
Details
Pay attention! This desoldering pump is intended for use on a central compressed air system.
The JBC MVE-A is a stand-alone pneumatic desoldering pump suitable for the JBC DDE-2C and JBC DME-2A control units. The pump works with the comfortable DS360 and DR560 desoldering irons.
By using compressed air and a Venturi valve, the MVE-A delivers the best results. The pump delivers a suction of 15 SLPM and a static pressure of 680 mm Hg. Optionally, the MVE-A can be controlled via the P-005 pedal.
JBC MSE-A
Are you looking for a self-contained desoldering pump? Look at the JBC MSE-A desoldering pump. The MS-A is an electric desoldering pump and therefore does not work with compressed air.
JBC Modular line
The JBC modular line allows you to connect your module to the desired control unit and extend it other modules. More information about the modular line can be found at this page.
The default 2-year warranty can be extended to 3 years by registering your device.
Specifications
| Static pressure (at 6 bar) | 680 mm HG (90% vacuum) |
| Flow rate | 15 SLPM [L/min] |
| Air pressure | 4 - 6 Bar |
| Dimensions | 225 x 145 x 55 mm |
| Weight | 700 grams |
| ESD-safe | Yes |
Accessories
The JBC MVE-A desoldering pump is supplied with:
- Connecting cable with control unit
- User manual
- Suction filter
- Cotton filters
- 50 paper filters
- Escape filter
Pros and cons
- High static pressure and flow rate
- Only works with compressed air
Downloads
| JBC MVE-A manual |  (1.53 MB) | Download |
