Details

This is the white variant of the SM-1BE

The SM-1BE stereo microscope delivers precise and clear images. A stereo microscope provides a 3D view, which makes it suitable for tasks such as soldering SMD components.

Trinocular and Simul-Focal

The SM-1BE is trinocular, meaning it has a third port available to connect a camera using the C-mount adapter. The SM-1BE is simul-focal, so the camera can be used simultaneously with the two eyepieces.

7x to 45x Magnification

The SM-1BE microscope offers a magnification range from 7x to 45x with a maximum working height of 100mm. For electronics use, we recommend using a 0.5x Barlow lens. This halves the microscope’s magnification and doubles the working distance (the distance between the objective and the stage).

Stand

The microscope features a solid base with a stand. It can be quickly positioned above, for example, a circuit board or a phone to be repaired. The stand allows you to raise or lower the microscope to bring it closer to or further from the object.

Specifications

Type	SM-1BE
Max. field of view	20 mm
Diopter adjustment	+/- 5dp
Pupil distance	Adjustable 55–75 mm
Shipping weight	~ 12kg

Accessories

LED ring light	Without lighting, it is very dark under a microscope. Don’t forget to order lighting as well.	LED ring 40.5 €40.50 Excl. VAT Info
Barlow lens 0.5x	A Barlow lens is mounted under the microscope’s objective, halves the microscope’s magnification, and doubles the working distance (distance between objective and stage).	Barlow lens 0.5x 32.23 €32.23 Excl. VAT Info
C-mount adapter 0.35x	A 0.35x C-mount adapter allows a C-mount camera to be connected to the microscope.	C-mount adapter 0.35x 48.76 €48.76 Excl. VAT Info
2K Camera	A 2K resolution camera with HDMI output and storage capabilities. If you’re looking for a higher-resolution camera, we recommend the 4K camera.	2K camera 205.79 €205.79 Excl. VAT Info
Premium rubber eyecups	Rubber eyecups offer more comfort and reduce incoming light.	Premium eyecups 6.61 €6.61 Excl. VAT Info
