Siglent SDS1102CML+ oscilloscope

279 €279.00 Excl. VAT

Loading stock info

Product number: ELE001295

Lowest price guaranteed

Details

The Siglent SDS1102CML+ is an affordable 2-channel oscilloscopes with a crisp high-resolution LCD display. Because the scope offers all features you expect on a basic oscilloscope and comes in a rigid enclosure with high quality electronics, the scope offers a great quality to price ratio.

These oscilloscopes feature a 2 MB memory, LCD screen and a sample rate up to 1 Gigasample/second. The scopes can be connected to the PC with USB. Furthermore, it is possible to insert a USB memory stick into the device for storing measurement data. This can be done as binary data or as a screenshot.

Do you want to take measurements on the 230V AC grid or three-phase electrical signals? Then you need the Siglent Isolated Front End module! This module isolates your oscilloscope from high voltages up to 600V peak-peak and has a bandwidth of 1MHz.

Models

The Siglent SDS1102CML+ is part of the SDS1000CML+ series. The models in this series differ in analogue bandwidth. The key specifications are displayed in the table below.

Model	SDS1072CML+	SDS1102CML+	SDS1152CML+
Number of channels	2	2	2
Analog bandwidth	70 MHz	100 MHz	150 MHz
Memory size	2 Mpts	2 Mpts	2 Mpts
Sample rate (1 channel active)	1 GS/s	1 GS/s	1 GS/s
Prijs	271.9 €271.90 Excl. VAT	279 €279.00 Excl. VAT	379.34 €379.34 Excl. VAT

Specifications

Memory size	2 MB/ 2 Mpts
Display	7" TFT, 800 x 480 pixels
Input impedance	1 MΩ
Rise Time	SDS1072CML+: ≤5 ns SDS1102CML+: ≤3.5 ns SDS1152CML+: ≤2.3 ns
Horizontal scale	SDS1072CML+: 5 ns/div - 50s/div SDS11x2CML+: 2.5 ns/div - 50 s/div
Vertical sensitivity	2 mV/div - 10 V/div
A/D convertor	8 bit resolution
Maximal voltage	400V (peak to peak)
Probe support	1x, 10x, 50x, 100x, 500x, 1000x
Number of channels	2
Connections	USB 2.0 type A, USB 2.0 type B, RS232, Pass/Fail trigger, RJ45 Ethernet
Eleshop noise production rating	★ ★ ★ ★
Weight (Without box)	2.5 Kg
Dimensions	323 x 136 x 157 mm (LxWxH)
