The Owon P4603 is a programmable lab power supply with a high resolution of 1mV and 1mA, and a low ripple of 1 mV. This power supply comes with a large 4 digit LED display to display current and voltage and is also equipped with automatic active cooling. It contains protection against overload, short-circuit and overheating. Furthermore, the P4603 is programmable via SPCI and LabVIEW on the PC and comes with an RS232 connection.
Output voltage | 0 - 60 V |
Output current | 0 - 3 A |
Power | Max. 180 W |
Resolution | 1 mV / 1 mA |
Ripple | < 1 mV rms (20 Hz - 20 MHz) |
Connectivity | RS232 |
Eleshop noise production rating | ★ ★ |
Weight | 5.6 kg |
Dimensions | 117 x 194 x 295 mm |
The Owon P4603 lab supply comes with the following accessories:
Owon P4000 series datasheet |
(95.13 KB) | Download |
Single Channel Output DC Power Supply Manual |
(1.86 MB) | Download |
