Micsig CP503B current probe
Details
The Micsig CP503B current probe with a 50 MHz bandwidth has an excellent price/quality ratio. Therefore, it is a very suitable option when you are looking for a more budgetproof current probe. Imporant to notice is that this current probe has a standard BNC interface which is suitable for all oscilloscopes. Moreover, the CP503B offers accurate and easy AC/DC measuring capabilities, a 6 A / 30 A range selection, overload indication and low current measurements and a 1% DC accuracy.
Model overview
| Model | CP503 | CP1003 | CP503B | CP1003B |
|---|---|---|---|---|
| Bandwidth | 50 MHz | 100 MHz | 50 MHz | 100 MHz |
| Rise time | ≤ 7 ns | ≤ 3.5 ns | ≤ 7 ns | ≤ 3.5 ns |
| Power interface | Micsig UPI | Micsig UPI | Standard BNC | Standard BNC |
| Delay | < 6 ns (6 A) < 6 ns (30 A) |
< 6 ns (6 A) < 6 ns (30 A) |
< 30 ns (6 A) < 30 ns (30 A) |
< 30 ns (6 A) < 30 ns (30 A) |
| Power supply | DC 12 V | DC 12 V | DC 5 V / 3 A | DC 5 V / 3 A |
| Price |
Specifications
| Current range | 6 A / 30 A |
| Input current range | 20 mA ~ 6 Apk（6 A） 50 mA ~ 30 Apk（30 A） |
| Maximum current input | 30 Apk，60 Apk-pk，21.21 Arms |
| Maximum working voltage | CAT II 300V |
| Output sensitivity | 1 V / 2 A (6 A) 1 V / 10 A (30 A) |
| Maximum conductor diameter | 5 mm |
| Overload indicator | Flashing light |
