Maynuo M9711 electronic load

The Maynuo M9711 electronic load is a programmable DC electronic load with a load power up to 150W. The load can be used in six high speed operation modes, and offers a resolution of 1 mV and 0.01 mA. Additionally, the M9711 will perform protection to over heating, over voltage, over current, over power, and polarity reversal. The possibilities that the load offers are extensive, and the functions include battery test, dynamic test, and even short circuit.

The 4 channel VFD screen of the M9711 can display two lines. The electronic load supports remote voltage compensation as well as multi-data storage, and edits arbitrary waveforms in list function.

The M97XX series feature a wide field of application, ranging from for example chargers, batteries, power supplies, to aeronautic and maritime solutions.

Specifications

Input power	150 W
Input current (max)	30 A
Input voltage (max)	150 V
Operation modes	CC, CR, CV, CW, CC+CV, CR+CV
Current setting resolution	0 - 3 A: 0.1 mA 0 - 30 A: 1 mA
Voltage setting resolution	0.1 - 19.999 V: 1 mV 0 - 150 V: 10 mV
Short circuit current	0 - 3 A: 3.3 A 0 - 30 A: 33 A
Short circuit resistance	55 mOhm
Dimensions	214 x 108 x 365 mm
Weight	3.5 kg
