Keysight U1733P LCR meter
Details
The U1733P is a handheld LCR meter Combo Kit. The U1730 series handheld LCR meter makes it possible to measure frequencies up to 100kHz, a feature normally only found in bank meters. The multimeter allows measurements to be made more quickly using the one-touch automatic identification function button which displays component type and more detailed component analysis such as Z, ESR and DCR.
Specifications
| Measurement specifications | |
| Resistance | 2 Ω - 200 MΩ |
| Capacity | 20 mF - 20 pF |
| Frequency | 100 Hz - 100 kHz |
| Display | 4 1/2 digit, 20000 counts |
| Battery life | 16 hours |
| Dimensions | 184 x 87 x 41 mm |
| Weight | 337 g |
Accessories
All Keysight U1733P meters come with:
- Soft carrying case
- IR to USB cable
- AC adapter
- SMD tweezers
