Keithley DMM7510 7.5 digit multimeter
Details
The Keithley DMM7510 is a highly accurate bench multimeter with a large 5-inch 7-1/2 digits (20,000,000 counts) intuitive graphical touchscreen display. With this multimeter it is possible to measure DC/AC voltage, DC/AC current, resistance, capacitance, temperature and frequency, in addition to a diode/continuity test, all with very accurate measurement ranges. The DMM7510 can measure DC/AC voltage, DC/AC current and resistance up to 10nV, 1pA and 0.1μΩ. The 1 MS/sec digitizer allows for the detection and analysis of voltage or current transients.
The multimeter offers connectivity via USB or LAN. These connections can be used to connect to a computer for data logging. In addition, the multimeter has a memory function for local storage of up to 27 million values.
Specifications
| Display resolution | 20,000,000 counts, 7 ½ digits |
| Max. AC voltage | 700 V |
| Max. DC voltage | 1000 V |
| Max. AC current | 10 A |
| Max. DC current | 10 A |
| Max. resistance | 1 GΩ |
| Max. capacitance | 1000 μF |
| Frequency | 3 Hz - 500 kHz |
| Temperature | -200 - 1820 ℃ |
| Other functions | Diode, continuity, statistics, DC voltage ratio, resistance measurement of 2 and 4 wires |
| True-RMS | Yes |
| Data logging | Yes |
| Display | 7 ½ digit, 5" TFT-LCD |
| Connectivity | LAN, USB |
| Dimensions | 213 x 88 x 410 mm |
| Weight | 4.08 kg |
Accessories
The Keithley DMM7510 7.5 digit multimeter comes with the following accessories:- Measurement leads
- USB interface cable
- TSP-link/Ethernet cable
- Power cord
- Touchscreen
- Extended measurement range
Pros and cons
