GW Instek SPS-606 power supply
Details
The GW Instek SPS-606 is a single-channel switched-mode DC power supply of 360W, which can be operated in CC and CV mode. It features an output voltage of 0-60V, and an output current of 0-6A. This power supply is accurate, given its high voltage regulation of 0.01% and the ability to compensate for cable losses between loads through remote sensing. Additionally, the output can be turned on/off remotely through terminals at the back; shorting these inputs will turn on the output, whereas it will be turned off otherwise.
Specifications
| Power | 360 W |
| Output voltage | 0 - 60 V |
| Output current | 0 - 6 A |
| Line regulation | Constant Voltage: ≤ 5 mV Constant Current: ≤ 3 mA |
| Load regulation | Constant Voltage: ≤ 5 mV Constant Current: ≤ 3 mA |
| Ripple | Constant Voltage: ≤ 5 mVrms Constant Current: ≤ 5 mArms |
| Noise | 100 mV peak-to-peak, 20 Hz - 20 MHz |
| Recovery time | ≤ 500 µs (50 % load change, minimum load 0.5 A) |
| Temperature coefficient | ≤ 100 ppm/℃ |
| Display | 3 1/2 digit 0.39" LED |
| Meter accuracy | ±(0.5 % of reading + 2 digits) |
| Dimensions | 128 x 151 x 295 mm |
| Weight | 3.2 kg |
Accessories
The SPS-606 comes by default with:
- Power cord
- Test lead GTL-203
- Declaration of traceable calibration
Pros and cons
- Compact size
- High accuracy
- Overvoltage protection
- Not programmable
Downloads
| GW Instek SPS series datasheet |  (91.98 KB) | Download |
| SPS series manual | (157.8 KB) | Download |
| DTC sample | (126.04 KB) | Download |
