Gossen Metrawatt M611D voltage tester
Details
The Gossen Metrawatt M611D voltage tester, is rated for DC and AC voltage tests in a voltage range from 12V to 1000V. When testing DC voltage, it is possible to perform polarity tests and when testing AC voltage, it is also possible to perform phase tests. The LED display shows what voltage is measured by the tester.
With CAT III and CAT IV security, it is possible to connect the battery-less meters to a power outlet without any worries. On top of that, the M611D voltage tester can also detect three-phase rotation, provided that the neutral point of the test object is grounded.
Lastly, the voltage tester is very ergonomic and sturdy due to its rugged housing design which includes a rubberized handle surface. Next to the LED display, the tester also has an integrated motor to generate vibrations when the user is measuring voltages.
Specifications
| Nominal frequency range | 0 - 60 Hz |
| Voltage measurement accuracy | ±15 % |
| Internal resistance | 180 kΩ |
| Operating and storage temperature range | -20 °C to +45 °C |
| Protection category | IP65 |
| Safety category | CAT IV 600 V & CAT III 1000 V |
| Dimensions | 85 x 53 x 330 mm |
| Weight | 250 g |
Pros and cons
- Phase testing
- No batteries needed
- Vibrating alert
- Non-digital display
