Flir TG268 thermal imaging camera
Details
The FLIR TG268 thermal imaging camera improves on the regular single-spot IR thermometers to see and evaluate hot and cold spots that could indicate problems. This simple-to-use camera is perfectly suited for commercial, enterprise and HVAC applications. The camera features a 2.4 inch screen to improve visibility and to simplify repairs. It uses the patented FLIR MSX © (Multi-Spectral Dynamic imaging), which is a system that includes visible light details to improve image clarity. Images can be easily recorded to the internal memory to visualize changes in temperature. The thermometer also features a built-in laser pointer to help aim the device.
This camera can be considered to be very sturdy as it has been drop-tested up to 2m. The possibility exists to mount the camera on a tripod, because it features a 1/4 inch mount connector on the handle bottom.
Specifications
| Range | -25 to 400 °C |
| Accuracy |
±1.5 °C for 50 °C – 100 °C ±2.5 °C for -25 °C – 50 °C ±2.5 °C for 100 °C – 400 °C |
| Response time | 150 ms |
| IR display resolution | 160 × 120 pixels (19,200 pixels) 320 × 240 (super resolution) |
| NETD | <50 mK |
| Detector type | Focal plane array (FPA), uncooled microbolometer |
| Screen | 2.4 inch (320 × 240 pixels) |
| Battery | 5 hours (4.5 with laser) |
| Measurements | 210 × 64 × 81 mm (H×W×D) |
| Net weight | 0.394 kg |
Accessories
The TG268 includes
- Printed documentation
- USB-A to USB-C cable
- Carry pouch
- Wrist band
Pros and cons
- Flir MSX
- High IR resolution
- Low response time
Downloads
| TG268 manual |  (11.28 MB) | Download |
| TG268 datasheet | (529.05 KB) | Download |
