EA-PS 9040-40T power supply
Details
The Elektro-Automatik EA-PS 9040-40T is a power supply capable of delivering 40V, 40A, and 1000W. This power supply consists of the things you need, it is able to do what it needs to do without a lot of extra features. This power supply can be controlled with the display and the knobs or can be programmed with the software/SCPI commands. It is possible to get optional interfaces like analog and LAN. With an efficiency of up to 92%, flexible power-regulated output, remote sensing, and auto ranging power stage, you have all that you need for testing.
Specifications
| Total power | 1000 W |
| Outputs | 1 |
| Output switch | Yes |
| Voltage range | 0 - 40 V |
| Current range | 0 - 40 A |
| Resolution | 10 mV/1 mA/1 W |
| Ripple | 4 mVrms / 6 mArms |
| Protection | OPP, OCP, OVP, OTP |
| Interfaces | USB A, USB B |
| Display | TFT touch panel |
| Dimensions | 92 x 239 x 461 mm |
| Weight | 8.5 kg |
Accessories
The PS 9040-40 T comes with:
- USB cable
- UK plug adapter
- Power cord
Pros and cons
- Compact design
- Up to a 1KW
- Interfaces like LAN and Analog are optional
Downloads
| EA-PS 9000T Datasheet |  (900.78 KB) | Download |
| EA-PS-9000T Manual ENG | (2.24 MB) | Download |
