EA-PS 2384-05B power supply
Details
The EA-PS 2384-05B from Elektro-Automatik is a desktop power supply and can deliver up to 332W with 84V and 5A. This power supply has 3 outputs where 2 are controllable with a combined maximum power delivery of 320W, and one output with a fixed voltage of 3 to 6V and a maximum power delivery of 12W. While you can use both outputs separately you can also put them in series or parallel with the tracking feature, and with the built-in USB port, you can control the supply from your PC with the included EA software or through SCPI. This power supply also comes with protective features like OVP, OCP, and OTP.
Specifications
| Total power | 332 W |
| Outputs | 3 |
| Output switch | Yes |
| Voltage rangeOutput 1Output 2Output 3 | 0 - 84 V0 - 84 V0 - 6 V |
| Current rangeOutput 1Output 2 | 0 - 5 A0 - 5 A |
| Power rangeOutput 1Output 2Output 3 | 160 W160 W12 W |
| Resolution | 10 mV/10 mA |
| Ripple | 24 mVrms / 3 mArms |
| Protection | OPP, OCP, OVP, OTP |
| Interfaces | USB B |
| Display | TFT colour display |
| Dimensions | 282 x 82 x 241 mm |
| Weight | 3.5 kg |
Accessories
The PS 2384-05B comes with:
- Power cord
Downloads
| EA-PS 2000B series datasheet |  (640.15 KB) | Download |
| PS 2000B manual | (1.26 MB) | Download |
