Aim TTi SMU4201 source measure unit
Details
The Aim TTi 4201 SMU has some great performance despite its compact size. With this SMU you get a power supply, load, DMM and a true arbitrary generator and due to the smaller size and lower price competitors like the Keithley 2450 seem very expensive. With the 6.5 digits and up to 0.1µV / 100fA resolution touchscreen combined with an advanced graph menu you can see and read the measurements very precisely. On top of this the 4201 SMU also has a measurement speed up to 200µs (5k/s). The internal memory is up to 100k measurements which gives you more than enough memory even with the fast measurement speeds.
Specifications
| Max voltage | 200V |
| Max current | 3A |
| Resolution | 0.1µV /100fA, 6.5 digits |
| Power | 25 W |
| Slew rate voltage | 21V/s to 0.12V/µs |
| Slew rate current | 3A/s to 36mA/µs |
| Protection | OPP, OCP, OVP, OTP |
| Modes | SV, SC, LC, LR, LP, MV, MC, MR, MHR |
| Interfaces | LAN, LXI, USB |
| Display | 3.5" TFT |
| Dimensions | 250 x 97 x 295 mm |
| Weight | 4.25 kg |
Accessories
This Aim TTi SMU4201 comes with:
- Power cord
Pros and cons
- Fast measurement speeds
- High resolution
- Compact size
Downloads
| General info |
 (248.45 KB) |
Download |
| Data sheet |
(4.42 MB) |
Download |
