| Output ranges | Range 1 - 0 to 35V, 0 to 3A
Range 2 - 0 to 15V, 0 to 5A
Range 3 - 0 to 35V, 0 to 500.0mA
|
| Total power | 228W
|
| Setting resolution | 1mV,0.1/1mA (depending on range)
|
| Setting accuracy | Voltage - 0.03% ±5mV
Current 0.2% ±5mA/0.5mA
|
| Load regulation | For any load change, at the output terminals, using remote sense, Voltage <0.01% + 2mV. Current <0.01% + 250µA; <0.01% +50µA on 500mA range.
(Add typically 2.5mV for a 0.5V drop in the positive output lead.)
|
| Line regulation | Voltage <0.01% + 2mV for 10% change.Current <0.01% +250µA; <0.01%+ 50µA on 500mA range
|
| Ripple and noise | Typically <0.35mV rms CV mode, and <0.2mA rms CI mode (<20µA rms on 500mA range)
|
| Common Mode Noise Current | <4µA rms at 20MHz bandwidth
|
| Transient Response | <20usec to within 15mV of setting for 90% load change
|
| Temperature Coefficient | <(50ppm+0.5mV)/ °C (voltage), <(100ppm+1mA/0.1mA)/°C (current)
|
